| model | Unit | CPCDY-35S |
| Rated load | Kg | 3500 |
| Load center distance | mm | 500 |
| Maximum lifting height of fork shelf with blocking | mm | 4260/4860 |
| Maximum lifting height | mm | 3000 |
| Full height of gantry fork landing, gantry vertical | mm | 1960 |
| Free lifting height | mm | 100 |
| Height of blocking rackcalculated from the fork surface of gantry | mm | 1227 |
| Distance from seat surface to roof protection frame | mm | 930 |
| Full height roof protection frame | mm | 2265 |
| Full lengthwithout fork | mm | 3670 |
| Front overhang distance | mm | 526 |
| Rear overhang | mm | 1075 |
| Wheel base | mm | 2090 |
| Towing pin height | mm | 754 |
| Minimum ground clearance | mm | 276 |
| Full width | mm | 1764 |
| Fork pitch outside max/min | mm | 1100/240 |
| Track width front/rear | mm | 1460/1460 |
| Outside of minimum turning radius | mm | 4289 |
| Inside of minimum turning radius | mm | 2328 |
| Minimum right angle radius width | mm | 4390 |
| Gantry tilt Angle(front/back) | mm | Front 8, back 10 |
| Fork size | mm | 1220*45*120 |
| Maximum driving speed full load/no load | Km/h | 30/35 |
| Speed increase full load/no load | mm/s | 350/500 |
| Speed decreasefull load/no load | mm/s | 550/450 |
| Maximum traction full load/no load | KN | 28 |
| Maximum climbing capacity full load/no load | % | 20/30 |
| Total weight | Kg | 4100 |
| Weight distribution full load front/rear | Kg | 6290/740 |
| Weight distribution no load front/rear | Kg | 1620/2350 |
| Number of wheels x/drive wheel | \ | 4X/4 |
| Tire type front/rear | \ | pneumatic tire |
| Front tire | \ | 23.5-16 |
| Rear tire | \ | 23.5-16 |
| Service brake | \ | Hydraulic brake |
| Parking brake | \ | machinery |
| Engine model | \ | B04-458 (optional) |
| Reducer model | \ | 265 |
| Engine power | KW | 36.8 |
| Engine torque/speed | N.M | 154N.M/1800r/min |
