| Unit | CPC(D)035 |
| Power type | / | Internal combustion engine (diesel) |
| Rated load | Kg | 3500 |
| Load center distance | mm | 500 |
| Size |
|
|
| Maximum lifting height of fork shelf with blocking | mm | 4260 |
| Maximum lifting height | mm | 3000 |
| Full height of gantry fork landing, gantry vertical | mm | 2081 |
| Free lifting height | mm | 100 |
| Height of blocking rackcalculated from the fork surface of gantry | mm | 1227 |
| Distance from seat surface to roof protection frame | mm | 1022 |
| Full height roof protection frame | mm | 2186 |
| Full lengthwithout fork | mm | 2852 |
| Front overhang distance | mm | 455 |
| Rear overhang | mm | 498 |
| Wheel base | mm | 1800 |
| Towing pin height | mm | 310 |
| Minimum ground clearance | mm | 174 |
| Full width | mm | 1234 |
| Fork pitch outside max/min | mm | 1100/240 |
| Track width front/rear | mm | 1030/992 |
| Outside of minimum turning radius | mm | 2407 |
| Inside of minimum turning radius | mm | 1582 |
| Minimum right angle radius width | mm | 2507 |
| Gantry tilt Angle(front/back) | mm | Front 6, Rear 12 |
| Fork size | mm | 1070*45*120 |
| Mechanical properties |
|
|
| Maximum driving speed full load/no load | Km/h | 18/20 |
| Speed increase full load/no load | mm/s | 350/500 |
| Speed decreasefull load/no load | mm/s | 550/450 |
| Maximum traction full load/no load | KN | 17 |
| Maximum climbing capacity full load/no load | % | 15/20 |
| Weight |
|
|
| Total weight | Kg | 4520 |
| Weight distribution full load front/rear | Kg | 6480/920 |
| Weight distribution no load front/rear | Kg | 1730/2580 |
| Wheels and tires |
|
|
| Number of wheels x/drive wheel | / | 2X/2 |
| Tire type front/rear | / | pneumatic tire |
| Front tire | / | 28*9-15 |
| Rear tire | / | 6.50-10 |
| Service brake | / | Hydraulic brake |
| Parking brake | / | machinery |
| Drive, transmission control device |
|
|
| Engine model | / | Quanchai/Xinchai 493 National IV |
| Reducer model | / | JDS30 |
| Engine power | KW | 36.8 |
| Engine torque/speed | N.M | 154N.M/1800r/min |
| Number of transmission shifts | / | Front 2, Rear 2 |
