1. The full-time four-wheel drive is unmatched by ordinary forklifts. It can work in soft places with strong driving force.
2. It can be produced according to customer needs, mechanical and continuously variable.
3. Three-phase oil-assisted braking system, caliper disc brake.
4. Fully enclosed cab.
5. Strong traction.
| Power type | diesel fuel |
Rated load (kg) | 3000 |
Load center (mm) | 500 |
Lifting height (mm) | 3000 |
Free lifting height (mm) | 100 |
Fork size (mm) | 1070*125*45 |
Mast angle (front/rear) | 6/12 |
Minimum turning radius (mm) | 2400 |
Minimum right-angle stacking channel width (mm) | 4280 |
Minimum right-angle channel width (mm) | Yunnei YN27GBZ2120 |
| Minimum ground clearance (mm) | 135 |
Height of overhead guard (mm) | 2160 |
| Front overhang (mm) | 495 |
| Maximum travel speed (full load Km/h) | 20 |
| Maximum lifting speed (full load mm/m) | 460 |
| Maximum traction (full load KN) | 20 |
| Maximum climbing ability (%) | 20 |
| Full length with fork (mm) | 3780 |
